Camera
- Image Sensor: 1/2.9″ Progressive Scan CMOS
- Max. Resolution: 1920 × 1080
- Min. Illumination: Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV
- 2.8 mm, horizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°
- 4 mm, horizontal FOV 80°, vertical FOV 44°, diagonal FOV 94°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F2.2
DORI
- DORI
- 2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m
- 4 mm, D: 55 m, O: 22 m, R: 11 m, I: 5 m
Illuminator
- Supplement Light Type: IR,White Light
- Supplement Light Range
- IR: up to 20 m
- White Light: up to 15 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
Video
- Main Stream
- 50 Hz: 25 fps (1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
- Sub-Stream
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Video Compression
- Main stream: H.265+/H.265/H.264+/H.264,
- Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline Profile,Main Profile,High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR,VBR
- Region of Interest (ROI): 1 fixed region for main stream
Audio
- Audio Type: Mono sound
- Audio Sampling Rate: 8 kHz/16 kHz
- Environment Noise Filtering: Yes
- Audio Compression: G.711ulaw/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
Network
- Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP,NTP, IGMP, IPv4, IPv6, UDP, QoS
- API: Open Network Video Interface (Profile S, Profile T),ISAPI,SDK
- Security: Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
- Simultaneous Live View: Up to 6 channels
- User/Host
- Up to 32 users
- 3 user levels: administrator, operator, and user
- Client: iVMS-4200,HiLookVision
- Web Browser
- Plug-in required live view: IE 10, IE 11
- Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Wide Dynamic Range (WDR): Digital WDR
- SNR: ≥ 52 dB
- Privacy Mask: 1 programmable polygon privacy mask
- Day/Night Switch: Day,Night,Auto,Schedule
- Image Enhancement: BLC,HLC,3D DNR
Interface
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage: NA
- Built-in Microphone: Yes,1 built-in microphone
- Reset Key: NA
Event
- Basic Event: Motion detection (support alarm triggering by specified target type (human)), exception
- Linkage: Notify surveillance center, send email, trigger recording, trigger capture
General
- Power: 12 VDC ± 25%, 0.42 A, max. 5 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W
- Material: Plastic
- Dimension: 138.8 mm × 60.9 mm × 57.9 mm (5.5″ × 2.4″ × 2.3″)
- Package Dimension: 163 mm × 75 mm × 75 mm (6.4″ × 3.0″ × 3.0″)
- Weight: Approx. 175 g (0.4 lb.)
- With Package Weight: Approx. 250 g (0.55 lb.)
- Storage Conditions: -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -30 °C to 45 °C (-22 °F to 113 °F). Humidity 95% or less (non-condensing)
- Language: English, Ukrainian
- General Function: Heartbeat,anti-banding,mirror,password protection,password reset via email
Approval
- EMC: FCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
- Safety: CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017
- Environment: CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
- Protection: IP67: IEC 60529-2013
