Description
Datasheet: DS-TCG227-AIR
User Manual: DS-TCG227-AIR
Camera
- Image Sensor: 1/2.8″ Progressive Scan CMOS
- Min. Illumination
- Color: 0.002Lux@(F1.2, AGC ON)
- B/W: 0.002Lux@(F1.2, AGC ON)
- Shutter Speed: 1/30 s to 1/100,000 s
- Lens: 3.1 mm to 9 mm
- IR Cut Filter: Support
Compression Standard
- Video Compression: H.265, H.264
- Video Bit Rate: 32 Kbps to 16 Mbps
- Max. Resolution: 1920 × 1200
- Image Settings
- Saturation: 0 to 100
- Brightness: 0 to 100
- Contrast: 0 to 100
- Gain: 0 to 100
- 3D DNR: Off, Normal and Expert modes are selectable.
- White balance: White Balance 1 and White Balance 2 are selectable.
- Image Format: JPEG
- Frame Rate: 25 fps(1920 × 1200)
Network
- Network Storage: TF
- Protocols: TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP Upload Pictures
- Security: User Authentication, Heartbeat, NTP
- API: ISAPI, SDK
Interfaces
- Serial Port: 1 RS-485 Port, 1 RS-232 Port
- Built-In LED: 2 built-in LEDs
- Audio Output: 1-ch audio output
- Triggered Input: 3-ch triggered input, including 1-ch I/O triggered input and 2-ch alarm input
- Relay Output: 2-ch relay output, support open/close of barrier gates
- Memory Card Slot: 1 TF card slot, up to 128GB
- Communication Interface: 1 RJ45 10M/100M/1000M Ethernet port
General
- Working Temperature: -30°C to 70°C (-22°F to 158°F)
- Working Humidity: 90% or less (non-condensing)
- Power Supply: 12 VDC, PoE (802.3af)
- Power Consumption: 12 VDC, 1.0 A, 20 W
- Protection Level: IP67, IK10
Snapshot
- Analytic: Support ANPR
- LED Control: Support automatic light control/time control of LEDs
- Picture Format: JPEG with configurable quality
Vehicle Recognition
- Vehicle Color: Red, yellow(including orange), green, blue, purple, brown, white, grey(including silvery), black
- Brand: Hyundai, Toyota, Kia, Honda, Volkswagen, Benz, Nissan, Ford, ISUZU, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, Hino, Peugeot, Ssang Yong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, UD Trucks, Subaru, IVECO, MINI, Jeep, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, SAIC Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Mercury, Joylong, Geely, Cadillac, Jinbei, Ankai, Haima, Foton, King Long, Dongfeng, Emgrand
- Country/Region Supported By ANPR
European and Russian-Speaking Regions:
Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, United Kingdom, Ireland, Germany, Italy, Austria, Israel, Ukraine, Kyrgyzstan, and Russian Federation
- ANPR Recognition Accuracy (Under Recommended Installation And Lighting Conditions)
- Capture rate > 98%
- Vehicle moving direction recognition accuracy > 96%
- Mistaken capture rate < 2% (entrance/exit), < 5% (checkpoint)
- European and Russian-Speaking Regions:
- LPR accuracy > 98%
- Country/Region recognition accuracy > 98%
- Vehicle Type: Car (including SUV, MPV, Pickup)/truck/bus/van
