Description
Detection Performance
- Detection Range: 10m(DS-PD2-P10P-W(433MHz))
- Angle: 85°(DS-PD2-P10P-W(433MHz))
- Velocity Range: 0.3m/s ~ 3.0m/s(DS-PD2-P10P-W(433MHz))
- Pet Immunity: 24kg(DS-PD2-P10P-W(433MHz))
Software Features
- Partition: 4
- Onboard Video Clips: Up to 2-ch onboard video
- Tamper-Proof: Tampering alarm(DS-PWA32-HS(433MHz) Front, rear, and bracket tamper signal input(DS-PD2-P10P-W(433MHz)) Front and rear(DS-PD1-MC-WWS(H)(433M)）
- Schedule: Auto Arm/Disarm Schedule
- SMS Notification: Support
- Phone Call Notification: Support
- Phone Numbers: 8
- Signal Strength Indication: Signal Strength Indicators (SSI)
- Firmware Undate Tools: Web client / iVMS-4200 / Hik-Connect
- Configuration Tools: Web client / iVMS-4200 / Hik-Connect
- Application: iVMS-4200, and mobile APP
- Protocol: SIA – Contact ID; EHome v5.0
- User: 13 (1 installer, 1 administrator, and 11 general user)
Hardware Features
- Alarm Input: 32
- Alarm Output: 32
- Indicator: LED
RF Transmission
- Frequency: 433MHz
- Modulation: 2GFSK(DS-PWA32-HS(433MHz)） FSK(DS-19K00-Y(433MHz)）
- RF Speed: 10kbps（DS-19K00-Y(433MHz)、DS-PD1-MC-WWS(H)(433M)）
- RF Range: 800m (Open Area)(DS-PWA32-HS(433MHz)、DS-PD2-P10P-W(433MHz))、DS-PD1-MC-WWS(H)(433M)）300m (Open area)（DS-19K00-Y(433MHz)）
Electrical Characteristics
- Power Supply: 5 VDC，10 W(DS-PWA32-HS(433MHz) CR2032 3.0V, 2-year power supply（DS-19K00-Y(433MHz)）
- Battery Type: 4520 mAh lithium backup battery(DS-PWA32-HS(433MHz) 1×CR123A(DS-PD2-P10P-W(433MHz)) 1×CR123A, 3.0V(DS-PD1-MC-WWS(H)(433M)）,CR2032 3.0V(DS-19K00-Y(433MHz))
- Battery Life Span: Rechargeable lithium battery, supports up to 12h power supply(DS-PWA32-HS(433MHz) 2 years Battery life (DS-PD2-P10P-W(433MHz)、(DS-PD1-MC-WWS(H)(433M)）、（DS-19K00-Y(433MHz)）
- Power Consumption: < 5.6 W
Wireless Transmission
- Wired Network: 10M/100M Self-adaptive
- Network Encryption: AES-128 encryption
- Cellular Network: GPRS
- Wi-Fi Standard: 802.11b/g/n
- Encryption: Supported
- Wi-Fi Channel: 2.4 G
General
- Operation Temperature: –10 °C to 55 °C(DS-PWA32-HS(433MHz)、DS-PD1-MC-WWS(H)(433M)、DS-19K00-Y(433MHz)） ‘-10℃~+40℃ (DS-PD2-P10P-W(433MHz))
- Operation Humidity: 10% to 90%
- Shell Material: PC+ABS
- Dimension(WxHxD): 155 × 155 × 35mm(DS-PWA32-HS(433MHz)) 117mm× 69mm× 50mm (DS-PD2-P10P-W(433MHz)) 84mm x 25mm x 20.99mm(DS-PD1-MC-WWS(H)(433M)）63mm x 49mm x 16mm(DS-19K00-Y(433MHz))
- Weight: 125g (DS-PD2-P10P-W(433MHz)) 37g(DS-PD1-MC-WWS(H)(433M)） 24.5g(DS-19K00-Y(433MHz))
- Application Scenario: indoor
- Color: White
- Installation Height: 1.8m ~ 2.4m(DS-PD2-P10P-W(433MHz))
- Bracket: Including 1 x Ceiling mounting bracket, 1 x Wall mounting bracket, used by DS-PD2-P10P-W(435MHz)
Audio
- Audio Output: 1, 1.5W
Device Management
- Keyfob: 8
- Wireless Siren: 4
- Tag Reader: 4
- Keypad: 4
