Description
Datasheet: DS-PR1-WB
User Manual: DS-PR1-WB
Quick Start Guide: DS-PR1-WB
Specification
Software features
- Auto paring: Supported
Hardware features
- Serial port: 2, for debug
- Tamper-Proof: 1, front and back
- Power switch: 1
Electrical characteristics
- Battery type: Built in Battery Li
- Power supply: 100 VAC to 240 VAC
- Operation humidity: 10％ to 90％
- Operation temperature: ﹣10°C to +55°C (The battery can not be charged at temperature lower than 10°C, please make sure the adapter is connected)
- Battery life span: Up to 35 hours at normal temperature(The battery working time can be significantly reduced at low temperatures)
Wireless transmission
- RF frequency: 433 MHz
- RF method: Two-way communication
- RF modulation: 2GFSK
- RF distance: 800 m (open area)
- Wireless security: AES-128
Display
- LEDs status: 3, Register/Signal (Green/Red), Power (Green), Fault (Amber)
General
- Installation method: Wall mounting
- Dimension(WxHxD): 150 mm × 150 mm × 25 mm
- Shell material: Plastic
- Color: White
- Weight: 372 g
Device management
- PIRCAM paring: Supported
