Description
Datasheet: DS-PDMCS-EG2-WB
User Manual: DS-PDMCS-EG2-WB
Quick Start Guide: DS-PDMCS-EG2-WB
Specification
Detection Performance
- Detection Method: Opening Contact
- Detection Gap: 52mm Max
Feature
- Digital Processing: Support
- Tamper Protection: Front;Rear
- Environment Temperature Indicator: Support
- Signal Strength Indicator: Support
Interface
- Power Switch: Power Up Enrolling
- LED Indicator: Blue (Alarm)
Transmission
- Transmission Technology: Tri-X Wireless
- Transmission Method: Two-Way RF Wireless
- Transmission Frequency: 433MHz
- Transmission Security: AES-128 Encryption
- Transmission Range(Free Space): 1Km
- Frequency Hopping: Support
- Enrolling Method: Power up;Remote ID;QR Code
Electrical Characteristics
- Standard Battery Life: Up to 3 years (standby time)
- Power Supply: Battery Powered
- Battery Type: CR2450 x 1
- Typical Voltage: 3V
General
- Operation Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Operation Humidity: 10% to 90%
- Dimension(WxHxD)
- 29mm × 69mm × 10mm
- 14mm × 69mm × 10mm
- Weight: 38g
- Mounting Method: Wall-mount(The device only supports wooden structure installation and cannot be installed on metal surface)
- Application Scenario: Indoor
