Description
Datasheet: DS-PDBG8-EG2-WB
User Manual: DS-PDBG8-EG2-WB
Quick Start Guide: DS-PDBG8-EG2-WB
Specification
Detection Performance
- Detection Method: Acoustic Sensor
- Detection Range: 8m
- Detection Angle: 120°
- Sensitivity: 2m;4m;6m;8m
- Glass Type: Float;Plate;Tampered;Wired;Laminated Leaded;Double Glazing
- Glass Thickness: 2.4mm to 6.4mm
- Glass Size: 0.3m x 0.3m to 3m x 3m
Feature
- Digital Processing: Support
- Tamper Protection: Front;Rear
- Environment Temperature Indicator: Support
- Signal Strength Indicator: Support
Interface
- Alarm Input: Normally Closed;Normally Open;Impulse Count
- Power Switch: Power Up Enrolling
- LED Indicator: Blue(Alarm)
Transmission
- Transmission Technology: Tri-X Wireless
- Transmission Method: Two-Way RF Wireless
- Transmission Frequency: 433MHz
- Transmission Security: AES-128 Encryption
- Transmission Range(Free Space): 1Km
- Frequency Hopping: Support
- Enrolling Method: Power up;Remote ID;QR Code
Electrical Characteristics
- Power Supply: Battery Powered
- Battery Type: CR123A × 2
- Typical Voltage: 3V
- Standard Battery Life: Up to 5 years (standby time)
General
- Operation Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Operation Humidity: 10% to 90%
- Dimension(WxHxD): 38.8mm × 107.0mm × 24.5mm
- Weight: 83g
- Mounting Method: Wall;Ceiling
- Application Scenario: Indoor
