Description
Datasheet: DS-D6055FL-B/S
Quick Start Guide: DS-D6055FL-B/S
Display
- Visual Angle: Horizontal: 178°, Vertical: 178°
- Resolution: 1920 × 1080@60 Hz
- Contrast: 3500 : 1
- Brightness: 500 cd/m2
- Backlight: LED backlight
- Screen Size: 54.5 inch
- Pixel Pitch: 0.21 x 0.63 mm
- Color Depth: 8 bit
- Response Time: 6.5 ms
- Refresh Rate: 60 Hz
- Color Gamut: 72% NTSC
- Screen Active Zone
- 1209.6(H) x 680.4(V) mm
- (476.22 x 267.87 inch)
- 1209.6(H) x 680.4(V) mm
Interface
- Video & Audio Output: /
- 1 x AUDIO OUT
- 2 x Built-in loudspeaker
- Data Transmission Interface: 2 x USB, 1 x TF Card
- Network Interface: 1 x LAN, Wi-Fi, BT 4.0
General
- Working Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Working Humidity: 0% to 90%
- Packing Dimensions
- 2100 (H) x 916 (V) x 303 (D) mm
(82.68 x 36.06 x 11.93 inch)
- 2100 (H) x 916 (V) x 303 (D) mm
- Power: 100 to 240VAC, 50/60 Hz
- Consumption: ≤ 150 W
- Standby Consumption: ≤ 10 W
- Product Dimensions
- 1958.2 (H) x 680.4 (V) x 450 (D) mm
(77.09 x 26.79 x 17.72 inch)
- 1958.2 (H) x 680.4 (V) x 450 (D) mm
- Net Weight: 66.190 kg (145.92 lb.)
- Gross Weight: 81.190 kg (178.99 lb.)
- Accessory: Screen, Base, Key, Screw Kit, Installation Manual
- Material Type: Supports DAT, MPG, VOB, TS, AVI, MKV, MP4, MOV, 3GP, TS, FLV, WEBM, ASF, MP1, MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ACC, M4A, XMF, MXMF, RTTTL, RTX, OTA, IMY, JPG, JPEG, BMP, GIF, PNG
Built-In System
- Memory: 2 GB
- Operating System: Android 6.0.1
- CPU: Cortex-A17, 4-core, 1.6 GHz
- SD Card: 8 GB EMMC, TF 32 GB
