Description
Datasheet: DS-D5032FC-A
User Manual: DS-D5032FC-A
General
- Loudspeaker: 2 W x 2, 6Ω
- VESA: M4, 100 mm × 100 mm
- Dimensions(W*H*D): 729mm x 433mm x 50mm / 728.8mm x 526mm x 167.2mm(with base)
- Packing Dimensions(W*H*D): 803mm x 513mm x 197mm
- Gross Weight: 9.25Kg
- Net Weight: 5.75kg
- Storage Temperature: -10 to 55 º C (-4 to 131 º F)
- Power Supply: AC 100 ~ 240 V , 50/60 Hz
- Working Temperature: 0 to 40 º C (32 to 104 º F)
- Working Humidity: 10 to 85 %
- Storage Humidity: 5 to 95%
- Standby Power Consumption: ≤ 0.5 W
- Power Consumption: ≤45W
- Color Of Casing: Black
Interfaces
- DVI Input: 1
- Audio (L/R): In×1，Out×1, 3.5 mm mini-jack
- HDMI Input: 1
- VGA Input: 1
- DVI Input: 1
- BNC Input: 1
- BNC Output: 1
- USB Interface: 1
Accessories
- Power Cord: 1
- User Manual: 1
- Warranty Card: 1
- VGA Cable: 1
- Base Bracket: 1
- Adapter: 1
Monitor
- Backlight: LED Backlight
- Screen Size: 31.5 inch
- Pixel Pitch: 0.36375 mm (H) × 0.36375 mm (V)
- Max Resolution: 1920×1080@60Hz
- Brightness: 300 cd/m²
- Contrast: 41.667361111111113
- Response Time: 8 ms
- Color: 16.7M
- Active Area: 698.40 mm x 392.85 mm
- Viewing Angle: Horizantal 178°, vertical 178°
Bracket
- Wall Mounted: Optional DS-DM1940W
- Base Bracket: Contain 1
