Description
Datasheet: DS-D5022QE-E
User Manual: DS-D5022QE-E
General
- Loudspeaker: NA
- VESA: M4, 100 mm × 100 mm
- Dimensions(W*H*D): 511mm × 377mm × 170mm(with base)/ 511mm × 313mm × 46mm
- Packing Dimensions(W*H*D): 565mm × 435mm × 105mm
- Gross Weight: 4.0kg
- Net Weight: 3.2 kg
- Storage Temperature: -20 to 60 º C (-4 to 131º F)
- Power Supply: 100 to 240 VAC, 50/60Hz
- Working Temperature: 0 to 40 º C (32 to 104 º F)
- Working Humidity: 10 to 90 %
- Storage Humidity: 5 to 95%
- Standby Power Consumption: ≤ 0.5 W
- Power Consumption: ≤ 30W
- Color Of Casing: Black
Interfaces
- HDMI Input: 1
- VGA Input: 1
Accessories
- Power Cord: 1
- User Manual: 1
- VGA Cable: 1
Monitor
- Backlight: TFT-LED Backlight
- Screen Size: 21.5 inch
- Pixel Pitch: 0.24825 mm (H) × 0.24825 mm (V)
- Max Resolution: 1920 ×1080@60Hz
- Brightness: 200 cd/m²
- Contrast: 600: 1
- Response Time: 5ms
- Color: 16.7M
- Active Area: 476.64mm× 268.11mm
- Viewing Angle: Horizontal 90°, vertical 65°
Bracket
- Pedestal: Contain 1
- Wall Mounted: Optional DS-DM1940W
