Description
Camera
- Image Sensor: 5 MP CMOS
- Signal System: PAL/NTSC
- Frame Rate
- TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
- CVI: 4MP@30fps, 4MP@25fps
- AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps
- CVBS: PAL/NTSC
- Resolution: 2560 (H) × 1944 (V)
- Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
- Lens: 2.8 mm, 3.6 mm, 6 mm fixed lens
- Horizontal Field Of View2.8 mm, horizontal FOV: 85.5°,vertical FOV: 63.7°, diagonal FOV: 110.7° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° 6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5°
- Lens Mount: M12
- Day & Night: ICR
- WDR (Wide Dynamic Range): Digital WDR
- Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 75°,Rotation 0 to 360°
Menu
- Image Mode: STD/HIGH-SAT
- AGC: Support
- Day/Night Mode: Auto/Color/BW (Black and White)
- White Balance: ATW/MANUAL
- Language: English
- Functions: Brightness, Sharpness, Mirror, Smart IR
Interface
- Video Output: Switchable TVI/AHD/CVI/CVBS
