Description
Datasheet: DS-2CE56H0T-ITZF
User Manual: DS-2CE56H0T-ITZF
Camera
- Image Sensor: 5 MP CMOS image sensor
- Max. Resolution: 2560 (H) × 1944 (V)
- Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time: PAL: 1/25 s to 1/50, 000 s, NTSC: 1/30 s to 1/50, 000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 340°; Tilt: 0° to 75°; Rotate: 0° to 355°
Lens
- Focal Length & FOV: 95.7° to 29.1°
- Lens Mount: Φ 14
- Image Settings: Brightness, Sharpness, DNR, Mirror, Smart IR
- Frame Rate: PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps
- Day/Night Mode: Auto/Color/BW (Black and White)
- Wide Dynamic Range (WDR): DWDR
- Image Enhancement: BLC
- White Balance: ATW/MWB
- AGC: Support
Interface
- Video Output: Switchable TVI/AHD/CVI/CVBS
General
- Material: Plastic
- Dimension: Ø 136 mm × 101.9 mm ( Ø 5.35″ × 4.01″)
- Weight: 410 g (0.90 lb.)
- Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- Communication: Up the coax, Protocol: HIKVISION-C (TVI output)
- Power Supply: 12 VDC ±15%, 24 VAC ±15%
- Consumption: Max. 4.4 W
- IR Range: Up to 40 m
