Description
Datasheet – DS-2CD2142FWD-I (W)(S)
User Manual – DS-2CD2142FWD-I (W)(S)
| Model | DS-2CE16H1T-IT1 |
|---|---|
| Image Sensor: | 1/3″ Progressive Scan CMOS |
| Min. Illumination: | 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR |
| Shutter time: | 1/3 s to 1/100,000 s |
| Lens: | 2.8mm, 4mm, 6mm @ F2.0 |
| Lens Mount: | M12 |
| Adjustment Range: | Pan: 0° ~ 355°, Tilt: 0° ~ 75°, Rotation: 0° ~ 355° |
| Day& Night: | IR cut filter with auto switch |
| Wide Dynamic Range: | 120 dB |
| Digital noise reduction: | 3D DNR |
| Video Compression: | H.264/MJPEG/H.264+ |
| H.264 code profile: | Main Profile |
| Video bit rate: | 32Kbps~16Mbps |
| Dual Stream: | Yes |
| Max. Image Resolution: | 2688 × 1520 |
| Frame Rate: | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) |
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC: | Yes, zone configurable |
| ROI: | Support |
| Network Storage: | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger: | Face Detection,Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
| System Compatibility: | ONVIF (Profile S, Profile G),ISAPI |
| Audio: | 1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model) |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet interface |
| Alarm: | 1x alarm I/O *only for –S models |
| On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: | Yes |
| Wireless Standards: | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range: | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth: | 20/40MHz Support |
| Modulation Mode: | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security: | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission Rate: | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
| Wireless Range: | 50m(depend on environment) |
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: | Max. 5W |
| Impact Protection: | IK10 |
| Weather Proof: | IP67 |
| IR Range: | Up to 30m |
| Dimensions: | Φ111 × 82 (4.4” × 3.2”) |
| Weight: | 500g (1.1lbs) |
| NOTE：: | “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
