C1C

EZVIZ-Logo COLOMBO CCTV

Key Features

  • 720p/1080p
  • Two-Way Talk
  • Supports 2.4GHz Wi-Fi
  • 110°/130° Wide-Angle Lens
  • Infrared Night Vision (Up to 12 meters)

Description


Datasheet: C1C

Name C1C 720p C1C 1080p
Model CS-C1C-D0-1D1WFR CS-C1C-D0-1D2WFR
Camera
Image Sensor 1/4″ Progressive Scan CMOS 1/2.9″ Progressive Scan CMOS
Shutter Speed Self-adaptive shutter Self-adaptive shutter
Lens 2.8mm, view angle:92° (Horizontal), 110°(Diagonal) 2.8mm, view angle:106° (Horizontal), 130°(Diagonal)
Lens Mount M12 M12
Day & Night IR-cut filter with auto-switching IR-cut filter with auto-switching
DNR 3D DNR 3D DNR
Max. Resolution 1280 x 720 1920 x 1080
Frame Rate Max. 25fps; Self-adaptive during network transmission Max. 20fps; Self-adaptive during network transmission
Compression
Video Compression H.264 H.264
Type H.264 Main profile Main profile
Video Bit Rate HD; Standard; Basic. Adaptive bit rate Ultra-HD; HD; Standard. Adaptive bit rate
Auto Bit Rate Self-adaptive Self-adaptive
Max. Bitrate 2Mbps 2Mbps
Network
Smart Alarm Motion detection Motion detection
Wi-Fi Pairing AP pairing AP pairing
Protocol EZVIZ cloud proprietary protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol EZVIZ cloud proprietary protocol
General Features Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark
Interface
Storage Support Micro SD card (Max. 256G) Support Micro SD card (Max. 256G)
Power Micro USB Micro USB
Wi-Fi
Standard IEEE802.11b, 802.11g, 802.11n IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz Supports 20MHz
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps 11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
General
Requirements – 10 – 45°C (14 – 113°F) Humidity 95% or less (non-condensing) – 10 – 45°C (14 – 113°F) Humidity 95% or less (non-condensing)
Power Supply DC 5V±10% DC 5V±10%
Power Consumption Max. 4.0W Max. 4.0W
IR Range Max. 12 meters Max. 12 meters
Product Dimensions 64mm x 64mm x 103mm 64mm x 64mm x 103mm
Packaging Dimensions 123mm x 79mm x 125.5mm 123mm x 79mm x 125.5mm
Weight 96g 96g
